| GENERAL DATA |
|---|
| | Type 85-IIM |
|---|
| Country of Origin | China |
|---|
| Role | Main battle tank |
|---|
| Date Of Introduction | 1991 |
|---|
| Crew | 3 |
|---|
| Combat Weight | 45.2 tons (41.0 mt) |
|---|
| Ground Pressure | 10.97 psi (0.771 kg/cm²) |
|---|
| Length, Overall |
33.73 ft (10.28 m) |
|---|
| Length, Hull |
23.95 ft (7.3 m) |
|---|
| Width, Overall |
11.32 ft (3.45 m) |
|---|
| Height, Turret Top |
7.55 ft (2.30 m) |
|---|
| Ground Clearance | 18.9 in (480 mm) |
|---|
| PERFORMANCE |
|---|
| | Type 85-IIM |
|---|
| Engine | 730 hp (544 kw) diesel |
|---|
| Range | 435 miles (700 km). 559 miles (900 km) with external tanks. |
|---|
| Road Speed | 35 mph (57 km/h) |
|---|
| Cross Country Speed | 22 mph (35 km/h) |
|---|
| Swim Speed | N/A |
|---|
| Fording Depth | 4.6 ft (1.4 m) unprepared, 7.9 ft (2.4 m) with snorkel |
|---|
| Grade | 60% |
|---|
| Trench Crossing | 8.9 ft (2.7 m) |
|---|
| Vertical Wall Climb | 2.6 ft (0.8 m) |
|---|
| PROTECTION |
|---|
| | Type 85-IIM |
|---|
| Armor | ? |
|---|
| Applique Armor | Track skirts. Composite panels available. |
|---|
| Explosive Reactive Armor | N/A |
|---|
| Active Protective System | N/A |
|---|
| NBC Protection System | Yes |
|---|
| Smoke Equipment | 12 x 81-mm smoke grenade launchers.
Vehicle engine exhaust smoke system. |
|---|
| ARMAMENT |
|---|
| Type 85-IIM |
|---|
| Type |
Mount |
Typical Ammo Load |
| 2A46M/ D-81TM 125mm smoothbore gun |
Turret; auto or manual loading |
42.
APFSDS-T, HEAT, Frag-HE |
| 7.62mm Type 59 machine gun |
Coaxial to main gun |
2,000 |
| 12.7mm Type 54 AA machine gun |
Turret roof |
500 |
|
| FIRE CONTROL |
|---|
| | Type 85-IIM |
|---|
| Fire Control System | ISFCS-212 (Image-Stabilized Fire Control System) |
|---|
| Main Gun Stabilization | 2-plane |
|---|
| Rangefinder | Laser |
|---|
| Infrared Searchlight | Yes |
|---|
